Gas & Diesel Cogeneration Systems

For gas and diesel engines, gas turbines, and micro turbine generator retrofit applications, we offer over 500 standard products to choose from.

We will provide a comprehensive analysis and quotation to fit your exact needs, typically within 24 hours. Our equipment can be adapted and assembled to fit any application or complete installation.

Product Application

Combustion Sources: Gas engines (reciprocating, turbo charged, naturally aspirated and rotary), diesel engines, gas turbine engines

Cogen Applications

  • Hospitals
  • Manufacturing Plants
  • Schools
  • Office Buildings
  • Shopping Malls
  • Drilling Platforms
  • Oil & Gas Plants
  • Marine

Equipment Variety

  • Exhaust steam generators
  • Large exhaust recovery silencers
  • Smaller specialized exhaust recovery silencers
  • Special heat transfer configurations
  • Recirculating engine jacket water boilers
  • Particular pinch point requirements
  • Exhaust or liquid control
  • Special heat sink requirements
  • Special heat transfer metallurgy requirements
  • Specific maintenance concerns
  • Optional equipment requirements
  • Installation space and weight concerns
  • Package system requirements

Anticipated Results

  • Tremendous fuel savings typically pay for equipment and installation within 1 to 3 years of average use.
  • Pollution reduction due to lowered annual fuel usage.
  • Lower exhaust temperatures and significantly reduced sound output levels (final sound attenuation is typically 15 - 25 dBA).

Series

Exhaust Steam Generator (ESG1)

Capacity: (400kW - 7MW)
Entering Gas Temps.: 600 - 1,600°F
Heat Sink Types: Supplemental steam demand and/or primary steam source for steam heating or process steam
ESG1 (download PDF - 500kb)

Heat Recovery Silencer - Radial (HRSR)

Capacity: (200kW - 6MW)
Entering Gas Temps.: 450 - 1,250°F
Heat Sink Types: Engine jacket water, process water, ethylene glycol
HRSR (download PDF - 655kb)

Heat Recovery Silencer - Axial (HRSA)

Capacity: 5 -150kW
Entering Gas Temps.: 450 - 1,250°F
Heat Sink Types.: Engine jacket water, process water, boiler water, ethylene glycol
HRSA (download PDF - 440kb)

U-Tube Recovery System (UTR)

Capacity: 15 - 300kW
Entering Gas Temps.: 450 - 1,600°F
Heat Sink Types: Engine jacket water, process water, boiler water, ethylene glycol, thermal transfer fluids
UTR (download PDF - 370kb)

U-Tube Recovery Unit 1 (UTR1)

Capacity: (200kW - 10MW)
Entering Gas Temps.: 450 - 1,600°F
Heat Sink Types: Process water, boiler feedwater, ethylene glycol, thermal transfer fluids
UTR1 (download PDF - 1.4mb)

Accessories

Cain offers several system-compatible accessories including ebullient steam generators, boiler feedwater systems, and unique bypass valves. In addition Cain offers a line of exclusive time automatic sootblowers which provide unmatched industry performance.
Accessories: (download PDF - 88kb)



Cain Industries is ASME and National Board Certified
